ELECTROAIR
ELECTROAIR

Electric Hot Air Generator

  • High Temperature fins tube type bundle Heater with Ni-Cr Wire
  • Easy Remove or Insert Design
  • Thyristor based Control panel
  • Multiple Zone Design for better turndown ratio
  • Zero pollution
  • No Chimney Required
  • User-Friendly design
  • Heaters along with outer canopy for safety
  • Cooling Exhaust on bank heater area
  • Special panel AC
Inquire now
ELECTROAIR
Features

Electric Hot Air Generator

The ELECTROAIR is a cutting-edge industrial heating solution engineered for high-precision air heating. Designed to replace traditional fuel-fired systems, it combines high-performance thermal engineering with intelligent automation to provide a clean, safe, and highly efficient heat source for a variety of industrial processes.

Technical Innovation & Performance

At the heart of the ELECTROAIR system is a high-temperature Finned Tube bundle heater utilizing premium Ni-Cr (Nickel-Chromium) wire. This design ensures rapid heat transfer and uniform air temperature distribution.

To maximize operational flexibility, the system features a Multiple Zone Design. This allows for an improved turndown ratio, enabling the unit to operate efficiently even at partial loads without compromising temperature stability.

Operating Range

  • Capacity – 50,000 to 40,00,000 Kcal/hr.
  • Fuel- Electric power
  • Temperature- up-to 350℃
Inquire Now

Key Features & Advantages

  • Precision Control: Equipped with a Thyristor-based control panel, the ELECTROAIR provides stepless, ultra-precise temperature management, ensuring your process stays within exact parameters.
  • Zero-Emission Operation: As an all-electric solution, it produces zero onsite pollution and requires no chimney, making it the ideal choice for facilities focusing on decarbonization and "Green Energy" initiatives.
  • Rapid Maintenance: The "Easy Remove-or-Insert" heater design allows for quick inspection or replacement of heating elements, significantly reducing potential downtime.
  • Enhanced Safety & Longevity: * Integrated heaters housed within an outer safety canopy.
    *Dedicated cooling exhaust system located near the bank heater area to prevent heat soak.
    *A specialized Panel AC to maintain optimal operating temperatures for the sensitive electronic control components.

Future-Ready Industrial Heating

Whether for space heating, industrial processing, or large-scale sanitation, the ELECTROAQUA provides a clean, quiet, and highly efficient hot water solution. Its wide range of regulation makes it the ideal choice for industries looking to transition toward electrification and sustainable energy management.

Technical Specifications

Specification Unit EA-05 EA-10 EA-20 EA-30 EA-40 EA-50 EA-60 EA-80 EA-100
General
heat Output K Cal/hr KCal/hr 50000 100000 200000 300000 400000 500000 600000 800000 1000000
Hot air Outlet Temperature °C 300 300 300 300 300 300 300 300 300
Hot air Inlet Temperature °C 30 30 30 30 30 30 30 30 30
Air Flow @ 300*C M³/hr 650 1300 2600 3900 5200 6500 7800 10400 13000
Air Pressure at HAG Outlet MMWC 100 100 100 100 100 100 100 100 100
Input Power Volts 415 V- 3Phase 50 Hz
Type of Fuel Fuel Electric Power
Boilers Efficiency
On Electric Heater % 98 +/-2 98 +/-2 98 +/-2 98 +/-2 98 +/-2 98 +/-2 98 +/-2 98 +/-2 98 +/-2
Power Consumption
Electric Power (860 Kcal/KW) KW/Hr 60 120 240 360 480 594 720 954 1188
Electrical Load
P.A. Fan with Motor H.P. 3.00 5.00 7.50 10.00 15.00 20.00 20.00 25.00 30.00
Input Heater Power H.P. 60 120 240 360 480 594 720 954 1188
Total Electric Load H.P. 63.00 125.00 247.50 370.00 495.00 614.00 740.00 979.00 1218.00
NOTE: In view of constant endeavors to improve our products, we reserve the right to alter or change above specifications without prior notice.

Frequently Asked Questions (FAQ) about Electric Hot Air Generator

Electric hot air generators offer 100% clean energy with zero emissions at the point of use. They eliminate the need for fuel storage, chimneys, and complex burner maintenance while providing much higher precision in temperature control.

The multiple zone design allows the system to engage only the required amount of heating power based on demand. This improves the turndown ratio, meaning the system can operate efficiently at low capacities without the constant "on/off" cycling that wears out components.

Thyristor controls provide smooth, continuous power regulation. This prevents electrical spikes, extends the life of the heating elements, and allows the system to maintain a very tight temperature tolerance (often within ±1°C).

The ELECTROAIR is designed for "Quick Maintenance." The heaters use an easy remove-or-insert design, allowing individual bundles to be serviced or replaced with minimal tools, significantly reducing your facility's downtime.

To ensure long-term reliability, the high-precision Thyristor controls and electronic components must be kept at a stable temperature. The integrated Panel AC protects these electronics from the high ambient heat often found in industrial environments, preventing premature failure.
